Jaw Crusher Model PE 200×300

The PE 200×300 jaw crusher is a small jaw crusher model with a maximum feed size of 150mm and capacity of 1-4 tons per hour. It is primarily used for crushing various materials such as stones, pebbles, limestone, and other minerals. This type of jaw crusher is often used in laboratory settings or small-scale production lines.

Here are some key specifications and features of the PE 200×300 jaw crusher model:

1. Feed Opening Size: 200mm x 300mm (7.87 inches x 11.81 inches)
2. Max Feed Size: 150mm (5.91 inches)
3. Adjustable Range of Output Size: 20mm to 50mm (approximately 0.79 inches to 1.97 inches)
4. Capacity: 1-4 tons per hour
5. Motor Power: 5.5 kW (approximately 7.4 horsepower)
6. Weight: Around 1 ton

Please note that these specifications can vary slightly depending on the manufacturer and specific design of the crusher. The PE 200×300 jaw crusher is suitable for small-scale operations or laboratory use due to its limited capacity. If you require higher capacity, you might want to consider larger models of jaw crushers.
